Air-Compressor

The Company's Business has since built with a stable, Young, Creative and Professional Technology and Corporate spirit of the Corporative Management team.

The Company Maninly engaged in manufacturing different types of air compressor such as a permanent magnet synchronize screw compressor, Fixed type screw compressor, Oil free Compressor, piston type reciprocating compressor, Air Dryer Air Receiver Tank, Filters and Compressor Relative Spare-Parts

Servoqual Top Air-Compressor

Air-Compressor

TECHNICAL SPECIFICATION

MODEL	PRESSURE	INSTALLED MOTER RATING (KW)	CFM	M / MIN	MACHINE DIMENSION (LBH) MM /(WEIGHT) KG	NOISE (dB)	AIR OUTLET (INCH)
KC - 10HP D	08 / 10 / 13	7.5	46 / 34 / 30	1.3 / 0.96 / 0.85	900600800 / 220	60 + 2	G 1/2”
KC - 15HP D	08 / 10 / 13	11	65 / 46 / 39	1.84 / 1.3 / 1.1	1100730980* / 350	62 + 2	G 3.4”
KC - 20HP D	08 / 10 / 13	15	88 / 71 / 60	2.49 / 2.01 / 1.7	1100730980 / 360	62 + 2	G 3/4”
KC - 25HP D	08 / 10 / 13	18.5	113 / 95 / 78	3.2 / 2.69 / 2.21	12008801080 / 510	64 + 2	G 1”
KC - 30HP D	08 / 10 / 13	22	131 / 113 / 99	3.71 / 3.2 / 2.8	12008801080 / 510	64 + 2	G 1”
KC - 40HP D	08 / 10 / 13	30	181 / 160 / 124	5.12 / 4.53 / 3.51	14609801230* / 650	66 + 2	G 1 1/2”
KC - 50HP D	08 / 10 / 13	37	240 / 191 / 138	6.8 / 5.41 / 3.91	14609801230 / 700	66 + 2	G 1 1/2”
KC - 60HP D	08 / 10 / 13	45	275 / 242 / 212	7.8 / 6.9 / 6.00	14609801230 / 780	66 + 2	G 1 1/2”
KC - 75HP D	08 / 10 / 13	55	365 / 307 / 265	10.33 / 8.69 / 7.5	175012801590 / 1250	68 + 2	G 2”
KC - 100HP D	08 / 10 / 13	75	476 / 410 / 346	13.48 / 11.61 / 9.8	175012801590 / 1350	68 + 2	G 2”
KC - 120HP D	08 / 10 / 13	90	561 / 501 / 419	15.88 / 14.18 / 11.86	245016601700 / 1950	70 + 2	G 2 1/2”
KC - 150HP D	08 / 10 / 13	110	717 / 600 / 516	20.3 / 16.99 / 14.61	245016601700 / 2200	70 + 2	G 2 1/2”
KC - 175HP D	08 / 10 / 13	132	883 / 706 / 636	25 / 19.99 / 18.01	245016601700 / 2500	70 + 2	G 2 1/2”
KC - 220HP D	08 / 10 / 13	160	1035 / 930 / 740	29.3 / 26.33 / 20.95	270014601900 / 3480	78 + 2	G 3”
