Air-Dryers

Air-Dryers

FEATURES

Easy Installation

Less Maintenance

Environment Friendly

Power saving

Inlet temperature 40 C degree

Dew point 2 C - 3 C degree

Servoqual Top Air-Dryers

Air-Dryers

Air-Dryers

Air-Dryers

Air-Dryers

TECHNICAL SPECIFICATION

BASE MODEL	CFM	PRESSURE	AIR CONNECTION IN/OUT	RATED POWER* KW AIR COOLED
KC - 10AD	45	16	1/2 BSP(F)	0.2
KC - 15AD	68	16	1BSP(F)	0.4
KC - 20AD	85	16	1BSP(F)	0.5
KC - 25AD	100	16	11/2 BSP(F)	0.6
KC - 30AD	134	16	1BSP(F)	1
KC - 40AD	180	16	11/2 BSP(F)	0.9
KC - 50AD	250	16	2 BSP(F)	1.4
KC - 60AD	300	16	2 BSP(F)	1.6
KC - 75AD	400	16	2 BSP(F)	1.9
KC - 100AD	500	16	3NBASME Flg	2.3
KC - 125AD	600	16	3”NBASME Flg	2.8
KC - 180AD	800	16	3”NBASME Flg	3.8
KC - 220AD	1000	16	4”NBASME Flg	5
KC - 250AD	1250	16	4”NBASME Flg	5.7
KC -300AD	1500	12.5	5”NBASME Flg	6.8
KC - 400AD	2000	12.5	6”NBASME Flg	8.7
KC - 500AD	2500	12.5	6”NBASME Flg	11
